Packer Image Building for Servers

Packer is an open-source tool for creating identical machine images for multiple platforms from a single source configuration. Using Packer, you define infrastructure images once in code, build them consistently, and deploy across different cloud providers and hypervisors. This guide covers HCL template syntax, builders for Docker and QEMU, provisioners for software installation, post-processors for image optimization, and CI/CD integration.

Table of Contents

1. Packer Overview
2. Packer Template Syntax
3. AWS Builder Configuration
4. Docker Builder
5. QEMU Builder
6. Provisioners
7. Post-Processors
8. Building Images
9. CI/CD Integration
10. Conclusion

Packer Overview

Packer automates the creation of machine images for cloud providers and virtualization platforms. Instead of manually building images through console or scripts, Packer defines image specifications in code, builds them consistently, and enables version control of your infrastructure.

Key benefits:

• Consistency: Build identical images every time
• Speed: Automate image building and boot faster with pre-configured images
• Version Control: Store image definitions in git
• Multi-Cloud: Build once for AWS, Azure, GCP, Docker simultaneously
• Testing: Validate images before deployment
• Reproducibility: Rebuild exactly when needed

Packer workflow:

1. Define template (HCL or JSON)
   ↓
2. Validate template
   ↓
3. Build image
   ├── Create builder environment
   ├── Run provisioners (install software)
   ├── Run post-processors (optimize)
   └── Save image
   ↓
4. Deploy image

Packer Template Syntax

Packer uses HCL for readable template definitions.

Basic template structure:

# variables.pkr.hcl
variable "aws_region" {
  type    = string
  default = "us-east-1"
}

variable "instance_type" {
  type    = string
  default = "t3.medium"
}

variable "ami_prefix" {
  type    = string
  default = "packer-example"
}

variable "environment" {
  type    = string
  default = "production"
}

# main.pkr.hcl
source "amazon-ebs" "ubuntu" {
  ami_name      = "${var.ami_prefix}-${formatdate("YYYY-MM-DD-hhmm", timestamp())}"
  instance_type = var.instance_type
  region        = var.aws_region
  source_ami_filter {
    filters = {
      name                = "ubuntu/images/hvm-ssd/ubuntu-focal-20.04-amd64-server-*"
      root-device-type    = "ebs"
      virtualization-type = "hvm"
    }
    owners      = ["099720109477"]  # Canonical
    most_recent = true
  }
  ssh_username = "ubuntu"

  tags = {
    Name        = "${var.ami_prefix}-image"
    Environment = var.environment
    BuildTime   = timestamp()
  }

  snapshot_tags = {
    Name = "${var.ami_prefix}-snapshot"
  }

  run_tags = {
    Name = "Packer Builder"
  }
}

build {
  sources = ["source.amazon-ebs.ubuntu"]

  provisioner "shell" {
    inline = [
      "echo 'Building image...'",
      "sudo apt-get update",
      "sudo apt-get install -y nginx"
    ]
  }
}

Variable definition and types:

# variables.pkr.hcl
variable "subnet_id" {
  type        = string
  description = "Subnet ID for builder instance"
  sensitive   = true
}

variable "instance_count" {
  type        = number
  description = "Number of instances to build"
  default     = 1
}

variable "tags" {
  type = map(string)
  description = "Tags to apply to AMI"
  default = {
    ManagedBy = "Packer"
  }
}

variable "packages" {
  type = list(string)
  description = "Packages to install"
  default = [
    "nginx",
    "curl",
    "wget"
  ]
}

# Use variables in template
output "ami_id" {
  value = aws_ami.ubuntu.id
}

# In template
tags = merge(var.tags, {
  Name = "My-Image"
})

AWS Builder Configuration

Build Amazon Machine Images (AMIs) from Packer.

Basic AMI builder:

source "amazon-ebs" "example" {
  ami_name        = "my-app-${local.timestamp}"
  instance_type   = "t3.micro"
  region          = "us-east-1"
  source_ami_filter {
    filters = {
      name = "ubuntu/images/hvm-ssd/ubuntu-focal-20.04-amd64-server-*"
      root-device-type = "ebs"
    }
    owners      = ["099720109477"]
    most_recent = true
  }
  ssh_username = "ubuntu"
}

build {
  sources = ["source.amazon-ebs.example"]

  provisioner "shell" {
    script = "scripts/setup.sh"
  }
}

Advanced AMI configuration:

source "amazon-ebs" "production" {
  ami_name              = "prod-app-${formatdate("YYYY-MM-DD", timestamp())}"
  instance_type         = var.instance_type
  region                = var.aws_region
  availability_zone     = var.availability_zone
  subnet_id             = var.subnet_id
  security_group_id     = var.security_group_id
  associate_public_ip   = false

  # Source AMI from custom image
  source_ami            = var.base_ami_id
  # or use filter
  source_ami_filter {
    filters = {
      name                = "ubuntu/images/hvm-ssd/ubuntu-jammy-22.04-amd64-server-*"
      root-device-type    = "ebs"
      virtualization-type = "hvm"
      state               = "available"
    }
    owners      = ["099720109477"]
    most_recent = true
  }

  ssh_username = "ubuntu"
  ssh_timeout  = "10m"

  # EBS configuration
  ebs_optimized = true
  root_volume_size = 50

  encrypt_boot = true
  kms_key_id   = var.kms_key_id

  # Tagging
  ami_description = "Production application image"

  tags = {
    Name        = "prod-app"
    Environment = "production"
    BuildDate   = timestamp()
    Version     = var.image_version
  }

  snapshot_tags = {
    Name = "prod-app-snapshot"
  }

  run_tags = {
    Name = "Packer Builder Instance"
  }

  # Permissions
  ami_users             = var.ami_users
  ami_groups            = ["default"]
  snapshot_users        = var.snapshot_users

  # Cleanup
  force_deregister      = true
  force_delete_snapshot = true
}

build {
  sources = ["source.amazon-ebs.production"]

  provisioner "file" {
    source      = "app/"
    destination = "/tmp/app"
  }

  provisioner "shell" {
    script = "scripts/install.sh"
  }
}

Docker Builder

Create Docker images with Packer.

Basic Docker builder:

source "docker" "ubuntu" {
  image  = "ubuntu:22.04"
  commit = true

  changes = [
    "ENTRYPOINT /usr/bin/myapp",
    "EXPOSE 8080",
    "ENV APP_ENV=production"
  ]
}

build {
  sources = ["source.docker.ubuntu"]

  provisioner "shell" {
    inline = [
      "apt-get update",
      "apt-get install -y nginx"
    ]
  }
}

Advanced Docker configuration:

source "docker" "application" {
  image  = "ubuntu:22.04"
  commit = true

  # Use existing container
  docker_name = "my-container"

  # Run in Docker
  run_command = [
    "-d",
    "-i",
    "-t",
    "--",
    "{{.Image}}"
  ]

  # Container configuration
  container_dir = "/tmp"

  # Export to archive
  export_path = "image.tar"

  # Device access
  privileged = false

  # Volume mounts
  volumes = {
    "/tmp" = "/host/tmp"
  }

  changes = [
    "ENV APP_VERSION=${var.app_version}",
    "WORKDIR /app",
    "EXPOSE 8080 8443",
    "ENTRYPOINT [\"/usr/bin/app\"]"
  ]
}

build {
  sources = ["source.docker.application"]

  provisioner "shell" {
    inline = [
      "apt-get update",
      "apt-get install -y nginx curl"
    ]
  }

  provisioner "file" {
    source      = "app/"
    destination = "/app"
  }

  post-processor "docker-tag" {
    repository = "myrepo/myapp"
    tags       = ["latest", "v${var.version}"]
  }

  post-processor "docker-push" {
    ecr_login       = true
    login_server    = var.registry_url
    aws_access_key  = var.aws_access_key
    aws_secret_key  = var.aws_secret_key
  }
}

QEMU Builder

Build images for KVM and QEMU hypervisors.

Basic QEMU builder:

source "qemu" "ubuntu" {
  iso_url           = "https://releases.ubuntu.com/22.04/ubuntu-22.04.1-live-server-amd64.iso"
  iso_checksum      = "file:https://releases.ubuntu.com/22.04/SHA256SUMS"
  output_directory  = "output-qemu"
  vm_name           = "ubuntu-22.04.qcow2"

  accelerator = "kvm"
  machine_type = "pc"

  cpus   = 2
  memory = 2048

  disk_size        = 10000
  disk_compression = true
  disk_image       = false

  format = "qcow2"

  http_directory = "http"

  boot_command = [
    "<tab>",
    "ip=dhcp ipv6.disable=1",
    " ds=nocloud-net;s=http://{{.HTTPIP}}:{{.HTTPPort}}/",
    "<enter>"
  ]

  boot_wait = "2s"

  headless = true

  shutdown_command = "echo 'packer' | sudo -S shutdown -P now"

  ssh_username = "ubuntu"
  ssh_password = "ubuntu"
  ssh_wait_timeout = "20m"
}

build {
  sources = ["source.qemu.ubuntu"]

  provisioner "shell" {
    inline = [
      "echo 'Building QEMU image'",
      "sudo apt-get update",
      "sudo apt-get install -y nginx"
    ]
  }
}

Provisioners

Provisioners run software installation and configuration.

Shell provisioner:

provisioner "shell" {
  # Inline commands
  inline = [
    "apt-get update",
    "apt-get install -y nginx curl wget",
    "systemctl enable nginx"
  ]
}

# Or script file
provisioner "shell" {
  script = "scripts/install-packages.sh"
}

# Multiple scripts
provisioner "shell" {
  scripts = [
    "scripts/setup.sh",
    "scripts/security.sh",
    "scripts/cleanup.sh"
  ]
}

# With environment variables
provisioner "shell" {
  environment_vars = [
    "APP_VERSION=1.0.0",
    "ENVIRONMENT=production"
  ]
  inline = [
    "echo Version is $APP_VERSION"
  ]
}

File provisioner:

# Copy file
provisioner "file" {
  source      = "app/config.yml"
  destination = "/tmp/config.yml"
}

# Copy directory
provisioner "file" {
  source      = "app/"
  destination = "/opt/app"
}

# Copy to local (from builder)
provisioner "file" {
  type            = "ssh"
  source          = "/opt/app/output.txt"
  destination     = "local/output.txt"
  direction       = "download"
}

Ansible provisioner:

provisioner "ansible" {
  playbook_file = "playbooks/main.yml"

  extra_arguments = [
    "-e", "environment=production",
    "-e", "app_version=${var.app_version}"
  ]

  ansible_env_vars = [
    "ANSIBLE_HOST_KEY_CHECKING=False"
  ]
}

# With inventory
provisioner "ansible" {
  playbook_file = "playbooks/main.yml"
  user          = "ubuntu"
  local_port    = 22
  host_alias    = "packer-instance"
}

Chef provisioner:

provisioner "chef-client" {
  chef_version = "16.6.14"

  run_list = [
    "recipe[base::default]",
    "recipe[nginx::default]"
  ]

  cookbook_paths = ["cookbooks"]

  server_url = var.chef_server_url
  user_id    = var.chef_user_id
  key        = file("keys/client.pem")
}

Post-Processors

Post-processors optimize and distribute images.

Docker tag and push:

post-processor "docker-tag" {
  repository = "myregistry.azurecr.io/myapp"
  tags       = ["latest", "v${var.version}"]
}

post-processor "docker-push" {
  ecr_login      = true
  login_server   = var.registry_url
  aws_access_key = var.aws_access_key
  aws_secret_key = var.aws_secret_key
}

Manifest for artifact tracking:

post-processor "manifest" {
  output     = "manifest.json"
  strip_path = true

  custom_data = {
    build_time   = timestamp()
    build_version = var.image_version
    source_ami    = data.aws_ami.ubuntu.id
  }
}

Vagrant box:

post-processor "vagrant" {
  output = "output/ubuntu-{{user `version`}}.box"

  only = ["source.amazon-ebs.ubuntu"]
}

post-processor "vagrant-cloud" {
  access_token        = var.vagrant_cloud_token
  box_checksum        = file("checksums.txt")
  box_checksum_type   = "sha256"
  box_tag             = "myorg/ubuntu"
  version             = var.version
  version_description = "Ubuntu 22.04 with Nginx"
}

Manifest with artifact info:

build {
  sources = [
    "source.amazon-ebs.ubuntu",
    "source.docker.ubuntu"
  ]

  # ... provisioners ...

  post-processor "manifest" {
    output = "manifest.json"

    custom_data = {
      image_version = var.image_version
      build_date    = timestamp()
      git_commit    = var.git_commit
    }
  }
}

Building Images

Build and test Packer images.

Validate template:

# Validate syntax and configuration
packer validate .

# Validate specific file
packer validate main.pkr.hcl

# With variable files
packer validate -var-file=prod.pkrvars.hcl .

Format code:

# Format HCL files
packer fmt .

# Check formatting
packer fmt -check .

Initialize template:

# Download required plugins
packer init .

# Upgrade plugins
packer init -upgrade .

Build image:

# Build using defaults
packer build .

# Build specific sources
packer build -only='amazon-ebs.ubuntu' .

# With variable overrides
packer build \
  -var "aws_region=us-west-2" \
  -var "instance_type=t3.small" \
  .

# With variable file
packer build -var-file=prod.pkrvars.hcl .

# Debug mode (keep builder instance running)
packer build -debug .

# Force build (remove existing)
packer build -force .

# Show build output
packer inspect main.pkr.hcl

Inspect output:

# After build, check manifest
cat manifest.json | jq .

# Output shows:
# {
#   "builds": [
#     {
#       "name": "amazon-ebs.ubuntu",
#       "builder_type": "amazon-ebs",
#       "build_time": 1234567890,
#       "files": [],
#       "artifact_id": "us-east-1:ami-0123456789abcdef0",
#       "artifact_file_id": "AMIid"
#     }
#   ],
#   "last_run_uuid": "abc123..."
# }

CI/CD Integration

Automate image builds in CI/CD pipelines.

GitHub Actions:

name: Build Packer Image

on:
  push:
    branches: [main]
    paths:
      - 'packer/**'
      - '.github/workflows/packer.yml'

jobs:
  build:
    runs-on: ubuntu-latest

    steps:
      - uses: actions/checkout@v3

      - uses: hashicorp/setup-packer@main

      - name: Validate
        run: packer validate packer/

      - name: Format check
        run: packer fmt -check packer/

      - name: Build image
        run: packer build -var-file=packer/prod.pkrvars.hcl packer/
        env:
          AWS_ACCESS_KEY_ID: ${{ secrets.AWS_ACCESS_KEY_ID }}
          AWS_SECRET_ACCESS_KEY: ${{ secrets.AWS_SECRET_ACCESS_KEY }}
          PACKER_LOG: 1

      - name: Upload manifest
        uses: actions/upload-artifact@v3
        with:
          name: packer-manifest
          path: manifest.json

GitLab CI:

stages:
  - validate
  - build

variables:
  PACKER_VERSION: "1.8.0"

before_script:
  - apt-get update && apt-get install -y wget unzip
  - wget https://releases.hashicorp.com/packer/${PACKER_VERSION}/packer_${PACKER_VERSION}_linux_amd64.zip
  - unzip packer_${PACKER_VERSION}_linux_amd64.zip

validate:
  stage: validate
  script:
    - packer validate packer/
    - packer fmt -check packer/

build_ami:
  stage: build
  script:
    - packer build -var-file=packer/prod.pkrvars.hcl packer/
  artifacts:
    paths:
      - manifest.json
  only:
    - main

Jenkins:

pipeline {
  agent any

  environment {
    AWS_REGION = 'us-east-1'
    AWS_CREDENTIALS = credentials('aws-credentials')
  }

  stages {
    stage('Validate') {
      steps {
        sh 'packer validate packer/'
      }
    }

    stage('Build') {
      steps {
        sh '''
          packer build \
            -var-file=packer/prod.pkrvars.hcl \
            packer/
        '''
      }
    }

    stage('Archive') {
      steps {
        archiveArtifacts artifacts: 'manifest.json'
      }
    }
  }
}

Conclusion

Packer standardizes image creation across platforms, enabling reproducible infrastructure deployments. By defining images as code, validating templates, and integrating with CI/CD pipelines, you create a foundation for consistent, rapidly deployable infrastructure. Combine Packer-built images with Terraform for Infrastructure-as-Code deployments that are reliable, auditable, and scalable.
