Configuración de TLS Mutuo (mTLS)

TLS Mutuo (mTLS) extiende TLS estándar requiriendo que tanto cliente como servidor se autentiquen entre sí usando certificados. A diferencia de HTTPS tradicional donde solo el servidor prueba su identidad, mTLS proporciona autenticación bidireccional, asegurando que solo clientes confiados accedan a servicios protegidos. Esta guía cubre configuración de CA, creación de certificado de cliente, configuración a través de Nginx/HAProxy/Apache, mecanismos de revocación, rotación de certificados y estrategias de solución de problemas.

Tabla de Contenidos

  1. Descripción General de mTLS
  2. Configuración de Autoridad de Certificación
  3. Creación de Certificado de Servidor
  4. Creación de Certificado de Cliente
  5. Configuración de mTLS de Nginx
  6. Configuración de mTLS de HAProxy
  7. Configuración de mTLS de Apache
  8. Revocación de Certificado
  9. Rotación de Certificado
  10. Prueba de mTLS
  11. Solución de Problemas

Descripción General de mTLS

Flujo de autenticación de mTLS:

  1. El cliente conecta y envía su certificado
  2. El servidor valida certificado de cliente contra CA
  3. El servidor presenta su certificado
  4. El cliente valida certificado de servidor
  5. Ambas partes verifican cadena de certificados

Beneficios:

  • Previene acceso de cliente no autorizado
  • Detecta credenciales de cliente comprometidas
  • Elimina necesidad de autenticación de contraseña
  • Apropiado para autenticación servicio-a-servicio
  • Sin secretos compartidos para robar

Casos de uso:

  • Comunicación de API interna
  • Service mesh (Istio, Linkerd)
  • Autenticación de microservicios
  • Acceso de administración/panel
  • Autenticación de dispositivo IoT

Configuración de Autoridad de Certificación

Cree una CA privada para certificados internos:

# Create CA directory
mkdir -p ~/ca/{private,certs,csr}
cd ~/ca

# Generate CA private key (4096-bit RSA)
openssl genrsa -out private/ca.key 4096

# Generate CA certificate (valid 10 years)
openssl req -new -x509 -days 3650 -key private/ca.key -out certs/ca.crt \
  -subj "/C=US/ST=State/L=City/O=Organization/CN=Internal-CA"

Verifique certificado de CA:

openssl x509 -in certs/ca.crt -text -noout

Cree configuración de CA para firma automatizada:

cat > ~/ca/ca.conf <<'EOF'
[ ca ]
default_ca = CA_default

[ CA_default ]
dir = /root/ca
certs = $dir/certs
crl_dir = $dir/crl
new_certs_dir = $dir/certs
database = $dir/index.txt
serial = $dir/serial
RANDFILE = $dir/private/.rand

default_crl_days = 30
default_crl_extensions = crl_ext
default_days = 365
default_md = sha256
name_opt = ca_default
cert_opt = ca_default
preserve = no
policy = policy_strict
unique_subject = no

[ policy_strict ]
countryName = match
stateOrProvinceName = match
organizationName = match
organizationalUnitName = optional
commonName = supplied
emailAddress = optional

[ policy_loose ]
countryName = optional
stateOrProvinceName = optional
localityName = optional
organizationName = optional
organizationalUnitName = optional
commonName = supplied
emailAddress = optional

[ req ]
default_bits = 4096
distinguished_name = req_distinguished_name
string_mask = utf8only
default_md = sha256
x509_extensions = v3_ca

[ req_distinguished_name ]
countryName = Country Name
stateOrProvinceName = State or Province Name
localityName = Locality Name
organizationName = Organization Name
organizationalUnitName = Organizational Unit Name
commonName = Common Name
emailAddress = Email Address

[ v3_ca ]
subjectKeyIdentifier = hash
authorityKeyIdentifier = keyid:always,issuer
basicConstraints = critical, CA:true
keyUsage = critical, digitalSignature, cRLSign, keyCertSign
EOF

Inicialice base de datos de CA:

cd ~/ca
touch index.txt
echo 1000 > serial

Creación de Certificado de Servidor

Cree certificado de servidor firmado por CA:

# Generate server private key
openssl genrsa -out ~/ca/private/server.key 4096

# Create server CSR (Certificate Signing Request)
openssl req -new -key ~/ca/private/server.key -out ~/ca/csr/server.csr \
  -subj "/C=US/ST=State/L=City/O=Organization/CN=api.example.com"

# Sign server certificate with CA
openssl ca -config ~/ca/ca.conf -extensions v3_ca -days 365 \
  -notext -md sha256 -in ~/ca/csr/server.csr \
  -out ~/ca/certs/server.crt

# Create combined certificate and key
cat ~/ca/certs/server.crt ~/ca/private/server.key > ~/ca/certs/server.pem

Agregue extensiones de certificado para mTLS:

# Create server config with SANs
cat > ~/ca/server.conf <<'EOF'
[ req ]
default_bits = 4096
distinguished_name = req_distinguished_name
req_extensions = v3_req

[ req_distinguished_name ]
countryName = Country Name
stateOrProvinceName = State or Province Name
commonName = Common Name

[ v3_req ]
subjectAltName = @alt_names

[ alt_names ]
DNS.1 = api.example.com
DNS.2 = *.api.example.com
DNS.3 = api.internal
IP.1 = 192.168.1.100
IP.2 = 10.0.0.1
EOF

# Generate CSR with extensions
openssl req -new -key ~/ca/private/server.key -out ~/ca/csr/server.csr \
  -config ~/ca/server.conf \
  -subj "/C=US/ST=State/L=City/O=Organization/CN=api.example.com"

Creación de Certificado de Cliente

Cree certificados de cliente para autenticación:

# Generate client private key
openssl genrsa -out ~/ca/private/client1.key 4096

# Create client CSR
openssl req -new -key ~/ca/private/client1.key -out ~/ca/csr/client1.csr \
  -subj "/C=US/ST=State/L=City/O=Organization/CN=app-service-1"

# Sign client certificate
openssl ca -config ~/ca/ca.conf -days 365 -notext -md sha256 \
  -in ~/ca/csr/client1.csr -out ~/ca/certs/client1.crt

# Create PKCS12 format (for some applications)
openssl pkcs12 -export -in ~/ca/certs/client1.crt \
  -inkey ~/ca/private/client1.key -out ~/ca/certs/client1.p12 \
  -name "App Service 1" -passout pass:password

Cree múltiples certificados de cliente:

# Batch create certificates
for client in app1 app2 app3 app4; do
  openssl genrsa -out ~/ca/private/$client.key 4096
  openssl req -new -key ~/ca/private/$client.key -out ~/ca/csr/$client.csr \
    -subj "/C=US/ST=State/L=City/O=Organization/CN=$client"
  openssl ca -config ~/ca/ca.conf -days 365 -notext -md sha256 \
    -in ~/ca/csr/$client.csr -out ~/ca/certs/$client.crt
done

Configuración de mTLS de Nginx

Configure Nginx para requerir y validar certificados de cliente:

upstream backend {
    server 192.168.1.100:8000;
    server 192.168.1.101:8000;
    keepalive 32;
}

server {
    listen 443 ssl http2;
    server_name api.example.com;

    # Server certificate and key
    ssl_certificate /etc/nginx/ssl/server.crt;
    ssl_certificate_key /etc/nginx/ssl/server.key;

    # Client certificate validation
    ssl_client_certificate /etc/nginx/ssl/ca.crt;
    ssl_verify_client on;
    ssl_verify_depth 2;
    ssl_client_session_cache shared:SSL:10m;

    # TLS Configuration
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers HIGH:!aNULL:!MD5;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;

    # Pass client certificate to backend
    proxy_set_header SSL-Client-Cert $ssl_client_cert;
    proxy_set_header SSL-Client-Verify $ssl_client_verify;
    proxy_set_header SSL-Client-Subject $ssl_client_s_dn;

    location / {
        # Optional: Allow access only to valid certs
        if ($ssl_client_verify != SUCCESS) {
            return 403;
        }

        proxy_pass http://backend;
        proxy_http_version 1.1;
        proxy_set_header Connection "";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }
}

# Optional client certificate section
server {
    listen 8443 ssl;
    server_name api.example.com;

    # Require valid client cert for admin
    ssl_client_certificate /etc/nginx/ssl/ca.crt;
    ssl_verify_client optional;

    location /admin {
        if ($ssl_client_verify != SUCCESS) {
            return 401;
        }
        # Admin only content
    }
}

Configuración de mTLS de HAProxy

Configure HAProxy para mTLS:

global
    log stdout local0
    tune.ssl.default-dh-param 2048

frontend https_in
    bind *:443 ssl crt /etc/haproxy/ssl/server.pem \
        ca-file /etc/haproxy/ssl/ca.crt \
        verify optional

    mode http
    option httpclose
    option forwardfor

    # Pass client certificate info
    http-request set-header X-SSL-Client-Cert %{+Q}[ssl_c_der,hex]
    http-request set-header X-SSL-Client-Verify %[ssl_c_verify]
    http-request set-header X-SSL-Client-Subject %{+Q}[ssl_c_s_dn]
    http-request set-header X-SSL-Client-CN %{+Q}[ssl_c_s_dn(cn)]

    # Deny requests without valid client cert
    http-request deny if !{ ssl_c_verify eq 0 }

    default_backend backend_servers

backend backend_servers
    balance roundrobin
    mode http
    server srv1 192.168.1.100:8000 check
    server srv2 192.168.1.101:8000 check

HAProxy avanzado con validación de certificado:

frontend https_in
    bind *:443 ssl crt /etc/haproxy/ssl/server.pem \
        ca-file /etc/haproxy/ssl/ca.crt \
        verify required

    http-request set-header X-Client-CN %{+Q}[ssl_c_s_dn(cn)]

    acl allowed_clients src -f /etc/haproxy/allowed_clients.txt
    acl client_cert_valid ssl_c_verify eq 0
    acl cert_cn_admin ssl_c_s_dn(cn) -i admin
    acl cert_cn_readonly ssl_c_s_dn(cn) -i readonly

    use_backend backend_admin if client_cert_valid cert_cn_admin
    use_backend backend_readonly if client_cert_valid cert_cn_readonly
    default_backend backend_servers

backend backend_admin
    balance roundrobin
    server srv1 192.168.1.100:8001 check

backend backend_readonly
    balance roundrobin
    server srv2 192.168.1.101:8001 check

backend backend_servers
    balance roundrobin
    server srv1 192.168.1.100:8000 check

Configuración de mTLS de Apache

Configure Apache para mTLS:

<VirtualHost *:443>
    ServerName api.example.com

    # Server certificate
    SSLCertificateFile /etc/apache2/ssl/server.crt
    SSLCertificateKeyFile /etc/apache2/ssl/server.key
    SSLCertificateChainFile /etc/apache2/ssl/ca.crt

    # Client certificate validation
    SSLVerifyClient require
    SSLVerifyDepth 2
    SSLCACertificateFile /etc/apache2/ssl/ca.crt

    # TLS Configuration
    SSLProtocol TLSv1.2 TLSv1.3
    SSLCipherSuite HIGH:!aNULL:!MD5
    SSLHonorCipherOrder on

    # Pass client info to backend
    SSLOptions +StdEnvVars
    RequestHeader set X-SSL-Client-Cert %{SSL_CLIENT_CERT}e
    RequestHeader set X-SSL-Client-Verify %{SSL_CLIENT_VERIFY}e
    RequestHeader set X-SSL-Client-Subject %{SSL_CLIENT_S_DN}e
    RequestHeader set X-SSL-Client-CN %{SSL_CLIENT_S_DN_CN}e

    <Location />
        ProxyPass http://192.168.1.100:8000/
        ProxyPassReverse http://192.168.1.100:8000/
    </Location>
</VirtualHost>

# Optional: Different policies for different paths
<VirtualHost *:443>
    ServerName api.example.com

    # Admin requires certificate
    <Location /admin>
        SSLVerifyClient require
    </Location>

    # Public API optional certificate
    <Location /public>
        SSLVerifyClient optional
    </Location>
</VirtualHost>

Revocación de Certificado

Implemente CRL (Certificate Revocation List) u OCSP:

Configuración de CRL

# Create CRL file
openssl ca -config ~/ca/ca.conf -gencrl -out ~/ca/crl/ca.crl

# Revoke a client certificate
openssl ca -config ~/ca/ca.conf -revoke ~/ca/certs/client1.crt

# Update CRL
openssl ca -config ~/ca/ca.conf -gencrl -out ~/ca/crl/ca.crl

# Verify revocation
openssl crl -in ~/ca/crl/ca.crl -text -noout

Configure Nginx con CRL:

ssl_crl /etc/nginx/ssl/ca.crl;
ssl_verify_client on;
ssl_verify_depth 2;

OCSP Stapling

Habilite OCSP stapling para certificados de cliente:

ssl_stapling on;
ssl_stapling_verify on;
ssl_stapling_responder "http://ocsp.example.com";

Rotación de Certificado

Implemente rotación de certificado automatizada:

#!/bin/bash
# Certificate rotation script

CERT_DIR="/etc/nginx/ssl"
CA_DIR="${HOME}/ca"

# Rotate certificates
for app in client1 client2 client3; do
  # Check if expiration is within 30 days
  EXPIRATION=$(openssl x509 -in ${CA_DIR}/certs/${app}.crt -noout -enddate | cut -d= -f2)
  DAYS_LEFT=$(( ($(date -d "$EXPIRATION" +%s) - $(date +%s)) / 86400 ))

  if [ "$DAYS_LEFT" -lt 30 ]; then
    echo "Rotating certificate for $app (expires in $DAYS_LEFT days)"

    # Generate new key and CSR
    openssl genrsa -out ${CA_DIR}/private/${app}-new.key 4096
    openssl req -new -key ${CA_DIR}/private/${app}-new.key \
      -out ${CA_DIR}/csr/${app}-new.csr \
      -subj "/C=US/ST=State/L=City/O=Organization/CN=$app"

    # Sign new certificate
    openssl ca -config ${CA_DIR}/ca.conf -days 365 -notext -md sha256 \
      -in ${CA_DIR}/csr/${app}-new.csr \
      -out ${CA_DIR}/certs/${app}-new.crt

    # Backup old cert and key
    mv ${CERT_DIR}/${app}.key ${CERT_DIR}/${app}.key.bak
    mv ${CERT_DIR}/${app}.crt ${CERT_DIR}/${app}.crt.bak

    # Install new cert and key
    cp ${CA_DIR}/private/${app}-new.key ${CERT_DIR}/${app}.key
    cp ${CA_DIR}/certs/${app}-new.crt ${CERT_DIR}/${app}.crt

    # Reload web server
    systemctl reload nginx
  fi
done

Programe rotación:

# Add to crontab
0 2 * * 0 /usr/local/bin/rotate-certs.sh

Prueba de mTLS

Pruebe configuración mTLS con curl:

# Test without client certificate (should fail)
curl -v https://api.example.com/ 2>&1 | grep -i certificate

# Test with client certificate
curl -v --cert ~/ca/certs/client1.crt \
  --key ~/ca/private/client1.key \
  --cacert ~/ca/certs/ca.crt \
  https://api.example.com/

# Verify certificate chain
openssl s_client -connect api.example.com:443 \
  -cert ~/ca/certs/client1.crt \
  -key ~/ca/private/client1.key \
  -CAfile ~/ca/certs/ca.crt

Pruebe con diferentes clientes:

# Test with client1
curl --cert ~/ca/certs/client1.crt --key ~/ca/private/client1.key \
  --cacert ~/ca/certs/ca.crt https://api.example.com/api/protected

# Test with client2
curl --cert ~/ca/certs/client2.crt --key ~/ca/private/client2.key \
  --cacert ~/ca/certs/ca.crt https://api.example.com/api/protected

Pruebas con Python:

import requests
from requests.auth import HTTPClientCertAuth

response = requests.get(
    'https://api.example.com/api/protected',
    cert=('/root/ca/certs/client1.crt', '/root/ca/private/client1.key'),
    verify='/root/ca/certs/ca.crt'
)
print(response.status_code)

Solución de Problemas

Verifique detalles del certificado:

# Check server certificate
openssl x509 -in /etc/nginx/ssl/server.crt -text -noout

# Check client certificate
openssl x509 -in ~/ca/certs/client1.crt -text -noout

# Verify certificate chain
openssl verify -CAfile ~/ca/certs/ca.crt ~/ca/certs/client1.crt

Pruebe validez del certificado:

# Check expiration
openssl x509 -in /etc/nginx/ssl/server.crt -noout -dates

# Check if revoked
openssl crl -in ~/ca/crl/ca.crl -text -noout | grep -i client1

Depure problemas de conexión:

# Verbose SSL handshake
openssl s_client -connect api.example.com:443 -showcerts \
  -cert ~/ca/certs/client1.crt -key ~/ca/private/client1.key

# Check Nginx logs
tail -f /var/log/nginx/error.log | grep -i ssl

# tcpdump TLS handshake
sudo tcpdump -i eth0 -A "tcp port 443" | head -100

Conclusión

mTLS proporciona autenticación mutua robusta entre clientes y servidores, esencial para asegurar comunicación de servicio interno. La configuración apropiada de CA, generación de certificados, configuración a través de proxies y gestión del ciclo de vida aseguran implementaciones de mTLS seguras y mantenibles. La rotación de certificados regular, monitoreo de revocación y pruebas exhaustivas mantienen la posición de seguridad y previenen fallos de autenticación.
