Traefik Reverse Proxy Installation

Traefik is a modern, open-source reverse proxy and load balancer designed specifically for microservices and containerized environments. Unlike traditional reverse proxies that require configuration file restarts, Traefik dynamically discovers services and automatically configures routing rules. This guide covers installation, configuration, and deployment of Traefik on your VPS or bare metal infrastructure.

Table of Contents

  1. System Requirements
  2. Installation Methods
  3. Binary Installation
  4. Docker Installation
  5. Static Configuration
  6. Dynamic Configuration
  7. Entrypoints Configuration
  8. Routers and Services
  9. Let's Encrypt Integration
  10. Dashboard Access
  11. Health Checks
  12. Troubleshooting

System Requirements

Before installing Traefik, ensure your system meets the following requirements:

  • Linux kernel version 3.10 or higher
  • 512 MB RAM minimum (2 GB recommended for production)
  • 100 MB disk space for binary
  • Network connectivity to your backend services
  • Root or sudo access for system-level installation

Traefik is written in Go and distributed as a single binary, making it lightweight and easy to deploy across various architectures including x86_64, ARM, and ARM64.

Installation Methods

Traefik can be installed through multiple approaches depending on your infrastructure:

  • Binary Installation: Direct deployment for bare metal servers
  • Docker/Docker Compose: Container-based deployment with volume management
  • Kubernetes: Native integration with orchestration platforms
  • Package Managers: Distribution-specific packages (limited availability)

Binary Installation

Start by downloading the latest Traefik binary from the official releases:

cd /tmp
wget https://github.com/traefik/traefik/releases/download/v2.10.0/traefik_v2.10.0_linux_amd64.tar.gz
tar xzf traefik_v2.10.0_linux_amd64.tar.gz

Create a dedicated user and directories for Traefik:

sudo useradd -r -s /bin/false -d /var/lib/traefik traefik
sudo mkdir -p /etc/traefik
sudo mkdir -p /var/lib/traefik
sudo mkdir -p /var/log/traefik
sudo chown -R traefik:traefik /var/lib/traefik /var/log/traefik

Move the binary to the system path:

sudo mv /tmp/traefik /usr/local/bin/traefik
sudo chmod +x /usr/local/bin/traefik

Verify the installation:

traefik version

Create a systemd service file for automatic startup:

sudo tee /etc/systemd/system/traefik.service > /dev/null <<EOF
[Unit]
Description=Traefik Reverse Proxy
Documentation=https://doc.traefik.io/traefik/
After=network-online.target
Wants=network-online.target

[Service]
Type=notify
User=traefik
Group=traefik
ExecStart=/usr/local/bin/traefik --configFile=/etc/traefik/traefik.yaml
Restart=on-failure
RestartSec=5s
StandardOutput=journal
StandardError=journal
SyslogIdentifier=traefik

[Install]
WantedBy=multi-user.target
EOF

Enable and start the service:

sudo systemctl daemon-reload
sudo systemctl enable traefik
sudo systemctl start traefik

Docker Installation

For containerized deployments, create a docker-compose.yml file:

version: '3.8'

services:
  traefik:
    image: traefik:v2.10
    restart: always
    ports:
      - "80:80"
      - "443:443"
      - "8080:8080"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - /etc/traefik/traefik.yaml:/traefik.yaml:ro
      - /etc/traefik/dynamic.yaml:/dynamic.yaml:ro
      - /var/lib/traefik/acme.json:/acme.json
    networks:
      - traefik
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.traefik.rule=Host(\`traefik.example.com\`)"
      - "traefik.http.routers.traefik.service=api@internal"
      - "traefik.http.routers.traefik.entrypoints=websecure"

networks:
  traefik:
    driver: bridge

Deploy using Docker Compose:

sudo docker-compose -f /etc/traefik/docker-compose.yml up -d

Static Configuration

Static configuration defines the entrypoints, API access, and global settings. Create /etc/traefik/traefik.yaml:

global:
  checkNewVersion: false
  sendAnonymousUsage: false

entryPoints:
  web:
    address: ":80"
    http:
      redirections:
        entrypoint:
          to: websecure
          scheme: https
  websecure:
    address: ":443"
    http:
      tls:
        certResolver: letsencrypt
        domains:
          - main: example.com
            sans:
              - '*.example.com'

api:
  dashboard: true
  insecure: false
  debug: false

providers:
  file:
    filename: /etc/traefik/dynamic.yaml
    watch: true
  docker:
    endpoint: "unix:///var/run/docker.sock"
    exposedByDefault: false
    watch: true

certificatesResolvers:
  letsencrypt:
    acme:
      email: [email protected]
      storage: /var/lib/traefik/acme.json
      httpChallenge:
        entryPoint: web
      certificatesDuration: 2160h

Set appropriate permissions:

sudo chown traefik:traefik /etc/traefik/traefik.yaml
sudo chmod 600 /etc/traefik/traefik.yaml

Dynamic Configuration

Dynamic configuration defines services, routers, and middlewares without requiring Traefik restart. Create /etc/traefik/dynamic.yaml:

http:
  routers:
    web-app:
      rule: "Host(`app.example.com`)"
      service: web-backend
      entrypoints:
        - websecure
      tls:
        certResolver: letsencrypt
      middlewares:
        - compression
        - rate-limit

  services:
    web-backend:
      loadBalancer:
        servers:
          - url: "http://192.168.1.100:8000"
          - url: "http://192.168.1.101:8000"
        healthCheck:
          path: /health
          interval: 10s
          timeout: 5s

  middlewares:
    compression:
      compress: {}
    rate-limit:
      rateLimit:
        average: 100
        period: 60s
        burst: 200

Enable file watching to apply configuration changes automatically:

sudo systemctl restart traefik

Entrypoints Configuration

Entrypoints define the network interfaces and ports where Traefik listens:

entryPoints:
  web:
    address: ":80"
    forwardedHeaders:
      insecure: false
      trustedIPs:
        - "10.0.0.0/8"
        - "172.16.0.0/12"
        - "192.168.0.0/16"

  websecure:
    address: ":443"
    http:
      tls:
        options: modern
        certResolver: letsencrypt

  ssh:
    address: ":22"
    transport: tcp

  metrics:
    address: ":8082"
    metrics:
      prometheus:
        manualRouting: true

Routers and Services

Routers determine which services handle incoming requests based on rules:

http:
  routers:
    api-router:
      rule: "Host(`api.example.com`) && PathPrefix(`/v1`)"
      service: api-backend
      entrypoints: [websecure]
      priority: 10
      middlewares:
        - api-auth
        - api-ratelimit

    static-router:
      rule: "Host(`cdn.example.com`)"
      service: static-content
      entrypoints: [websecure, web]

  services:
    api-backend:
      loadBalancer:
        servers:
          - url: "http://api1.internal:8080"
          - url: "http://api2.internal:8080"
          - url: "http://api3.internal:8080"
        stickySessions:
          cookie:
            name: "TRAEFIK_BACKEND"
            httpOnly: true
            secure: true
            sameSite: "Strict"

    static-content:
      loadBalancer:
        servers:
          - url: "http://192.168.1.50:80"
        healthCheck:
          path: /
          interval: 30s
          timeout: 10s

Let's Encrypt Integration

Configure automatic HTTPS certificate management:

certificatesResolvers:
  letsencrypt:
    acme:
      email: [email protected]
      storage: /var/lib/traefik/acme.json
      httpChallenge:
        entryPoint: web
      caServer: https://acme-v02.api.letsencrypt.org/directory

  letsencrypt-staging:
    acme:
      email: [email protected]
      storage: /var/lib/traefik/acme-staging.json
      httpChallenge:
        entryPoint: web
      caServer: https://acme-staging-v02.api.letsencrypt.org/directory

Ensure the acme.json file has correct permissions:

sudo touch /var/lib/traefik/acme.json
sudo chmod 600 /var/lib/traefik/acme.json
sudo chown traefik:traefik /var/lib/traefik/acme.json

Dashboard Access

Enable the Traefik dashboard for monitoring:

api:
  dashboard: true
  insecure: false
  debug: false

http:
  routers:
    dashboard:
      rule: "Host(`traefik.example.com`)"
      entrypoints: [websecure]
      service: api@internal
      tls:
        certResolver: letsencrypt
      middlewares:
        - dashboard-auth

  middlewares:
    dashboard-auth:
      basicAuth:
        users:
          - "admin:$apr1$xyz123$encrypted_password_here"

Generate HTTP basic auth credentials:

sudo apt install apache2-utils
htpasswd -c /etc/traefik/.htpasswd admin

Access the dashboard at https://traefik.example.com with the configured credentials.

Health Checks

Configure health checking for backend services:

http:
  services:
    backend:
      loadBalancer:
        servers:
          - url: "http://192.168.1.10:8000"
          - url: "http://192.168.1.11:8000"
        healthCheck:
          path: /health
          interval: 10s
          timeout: 5s
          scheme: http
          headers:
            X-Check: "health"

Monitor health check status in the Traefik dashboard or logs:

sudo journalctl -u traefik -f

Troubleshooting

Check Traefik logs for configuration errors:

sudo systemctl status traefik
sudo journalctl -u traefik -n 50 -f

Validate configuration syntax:

traefik --configFile=/etc/traefik/traefik.yaml --testConfig

Verify entrypoints are listening:

sudo netstat -tlnp | grep traefik

Check Docker provider connectivity:

ls -l /var/run/docker.sock

Test backend service connectivity:

curl -i http://192.168.1.100:8000/health

Conclusion

Traefik provides a powerful, modern reverse proxy solution with automatic service discovery, dynamic configuration, and Let's Encrypt integration. Whether deploying on bare metal or containerized environments, Traefik's flexibility and performance make it an excellent choice for modern infrastructure. Regular monitoring through the dashboard and log files ensures reliable operation of your services.
