Benchmarking with wrk and siege

Introduction

While Apache Bench (ab) is excellent for simple benchmarking, wrk and siege offer advanced features for more realistic and flexible load testing. Wrk provides scriptable Lua-based tests with multi-threaded performance, while siege supports URL lists and complex testing scenarios. Both tools are essential for comprehensive web server performance testing and capacity planning.

Wrk is a modern HTTP benchmarking tool capable of generating significant load with a single multi-core machine. It combines multi-threading with an event-driven design (epoll/kqueue) to efficiently handle millions of connections. Siege specializes in realistic testing with support for multiple URLs, random delays, and transaction-based testing that simulates actual user behavior.

This comprehensive guide covers installation, usage, scripting, result interpretation, and real-world testing scenarios for both wrk and siege. You'll learn how to conduct advanced performance tests that accurately represent production workloads.

wrk: Modern HTTP Benchmarking

Installation

# Ubuntu/Debian - compile from source
apt-get install build-essential libssl-dev git -y
git clone https://github.com/wg/wrk.git
cd wrk
make
sudo cp wrk /usr/local/bin/

# Verify installation
wrk --version

Basic Usage

# Basic syntax
wrk -t<threads> -c<connections> -d<duration> URL

# Simple test: 12 threads, 400 connections, 30 seconds
wrk -t12 -c400 -d30s http://localhost/

# Example output:
Running 30s test @ http://localhost/
  12 threads and 400 connections
  Thread Stats   Avg      Stdev     Max   +/- Stdev
    Latency    42.15ms   18.34ms  312.45ms   87.23%
    Req/Sec   785.43     124.56     1.23k    68.45%
  282450 requests in 30.02s, 1.45GB read
Requests/sec:   9408.23
Transfer/sec:     49.56MB

Understanding wrk Output

# Thread Stats:
Latency    42.15ms   18.34ms  312.45ms   87.23%
# Avg: Average latency (42.15ms)
# Stdev: Standard deviation (18.34ms) - consistency measure
# Max: Maximum latency (312.45ms)
# +/- Stdev: 87.23% of requests within 1 standard deviation

Req/Sec   785.43     124.56     1.23k    68.45%
# Avg: Requests per second per thread (785)
# Stdev: Variation (124.56)
# Max: Peak requests per second (1,230)
# +/- Stdev: Consistency percentage

# Summary:
282450 requests in 30.02s, 1.45GB read
# Total requests completed
# Test duration
# Total data transferred

Requests/sec:   9408.23
# Overall throughput (most important metric)

Transfer/sec:     49.56MB
# Bandwidth used

Advanced Options

# Custom HTTP headers
wrk -t12 -c400 -d30s -H "Authorization: Bearer token123" http://localhost/api/

# Multiple headers
wrk -t12 -c400 -d30s \
    -H "Authorization: Bearer token123" \
    -H "Accept: application/json" \
    -H "User-Agent: wrk-benchmark" \
    http://localhost/api/

# Timeout configuration
wrk -t12 -c400 -d30s --timeout 10s http://localhost/

# Latency distribution
wrk -t12 -c400 -d30s --latency http://localhost/

# Output with latency:
  Latency Distribution
     50%   38.24ms
     75%   52.67ms
     90%   68.45ms
     99%  145.23ms

wrk Lua Scripting

Basic Script Structure

-- request.lua
-- Customize request generation

wrk.method = "POST"
wrk.body   = '{"name":"test","email":"[email protected]"}'
wrk.headers["Content-Type"] = "application/json"

-- Request function (called for each request)
request = function()
    return wrk.format(wrk.method, wrk.path, wrk.headers, wrk.body)
end

-- Response function (called for each response)
response = function(status, headers, body)
    if status ~= 200 then
        print("Error: " .. status)
    end
end

-- Done function (called when test completes)
done = function(summary, latency, requests)
    print("Total requests: " .. summary.requests)
    print("Total errors: " .. summary.errors.connect + summary.errors.read + summary.errors.write + summary.errors.timeout)
end

# Run with script
wrk -t12 -c400 -d30s -s request.lua http://localhost/api/users

Advanced Script: Multiple Endpoints

-- multi-url.lua
-- Test multiple endpoints randomly

local urls = {
    "/",
    "/products",
    "/products/1",
    "/api/users",
    "/api/orders"
}

request = function()
    -- Select random URL
    local path = urls[math.random(#urls)]
    return wrk.format("GET", path)
end

-- Track response times by path
local responses = {}

response = function(status, headers, body)
    local path = wrk.path
    if not responses[path] then
        responses[path] = {count = 0, errors = 0}
    end

    responses[path].count = responses[path].count + 1
    if status ~= 200 then
        responses[path].errors = responses[path].errors + 1
    end
end

done = function(summary, latency, requests)
    io.write("Path Statistics:\n")
    for path, stats in pairs(responses) do
        io.write(string.format("  %s: %d requests, %d errors (%.2f%%)\n",
            path, stats.count, stats.errors,
            (stats.errors / stats.count) * 100))
    end
end

Authentication Script

-- auth.lua
-- Test with authentication

local token = nil

-- Setup function (called once before test)
setup = function(thread)
    thread:set("token", "Bearer abc123xyz789")
end

-- Init function (called for each thread)
init = function(args)
    token = args.token
end

request = function()
    wrk.headers["Authorization"] = token
    return wrk.format("GET", wrk.path)
end

POST with Dynamic Data

-- dynamic-post.lua
-- Generate unique POST data for each request

local counter = 0

request = function()
    counter = counter + 1

    local body = string.format([[
        {"id": %d, "name": "User%d", "email": "user%[email protected]"}
    ]], counter, counter, counter)

    return wrk.format("POST", "/api/users", nil, body)
end

siege: Transaction-Based Benchmarking

Installation

# Ubuntu/Debian
apt-get install siege -y

# CentOS/Rocky Linux
dnf install siege -y

# From source
wget http://download.joedog.org/siege/siege-latest.tar.gz
tar -xzf siege-latest.tar.gz
cd siege-*/
./configure
make
sudo make install

# Verify installation
siege --version

Basic Usage

# Simple test: 25 concurrent users, 100 repetitions
siege -c25 -r100 http://localhost/

# Timed test: 25 concurrent users, 60 seconds
siege -c25 -t60s http://localhost/

# Example output:
Transactions:                  2450 hits
Availability:                 98.00 %
Elapsed time:                 59.87 secs
Data transferred:             12.45 MB
Response time:                 0.61 secs
Transaction rate:             40.93 trans/sec
Throughput:                    0.21 MB/sec
Concurrency:                  24.89
Successful transactions:      2450
Failed transactions:            50
Longest transaction:           3.45
Shortest transaction:          0.12

Understanding siege Output

Transactions:                  2450 hits
# Total successful requests

Availability:                 98.00 %
# Success rate (should be > 99%)

Response time:                 0.61 secs
# Average response time (lower is better)

Transaction rate:             40.93 trans/sec
# Throughput (requests per second)

Concurrency:                  24.89
# Average concurrent connections
# Should be close to -c value (25 in example)
# Lower = waiting for server responses

Longest transaction:           3.45
Shortest transaction:          0.12
# Response time range

Multiple URLs (URL List)

# Create URL list file
cat > urls.txt << 'EOF'
http://localhost/
http://localhost/products
http://localhost/about
http://localhost/contact
http://localhost/api/users
EOF

# Test all URLs randomly
siege -c50 -t60s -f urls.txt

# Test URLs sequentially (internet mode)
siege -c50 -t60s -i -f urls.txt

# -i: Internet mode (random URL selection)
# Without -i: Sequential access

POST Requests

# Simple POST
siege -c10 -r50 "http://localhost/api/users POST {\"name\":\"test\"}"

# POST with URL list
cat > post-urls.txt << 'EOF'
http://localhost/api/users POST {"name":"User1","email":"[email protected]"}
http://localhost/api/products POST {"name":"Product1","price":29.99}
http://localhost/api/orders POST {"user_id":1,"product_id":1}
EOF

siege -c25 -t60s -f post-urls.txt

Headers and Authentication

# Custom headers
siege -c25 -t30s \
    -H "Authorization: Bearer token123" \
    -H "Accept: application/json" \
    http://localhost/api/

# From configuration file
# Edit ~/.siege/siege.conf or /etc/siege/siege.conf
# Add:
# header = Authorization: Bearer token123
# header = Accept: application/json

Configuration Options

# View configuration
siege --config

# Common settings in siege.conf:
# connection = close          # Use keep-alive: connection = keep-alive
# timeout = 30                # Socket timeout
# failures = 1024             # Failures before giving up
# delay = 0                   # Delay between requests (seconds)
# chunked = true              # Handle chunked encoding
# verbose = false             # Verbose output
# show-logfile = true         # Show log file location
# logging = true              # Enable logging

Real-World Testing Scenarios

Scenario 1: Before/After Optimization Comparison

wrk Test:

#!/bin/bash
# compare-wrk.sh

URL="http://localhost/"

echo "=== BEFORE Optimization ==="
wrk -t12 -c400 -d30s --latency $URL | tee before-wrk.txt

read -p "Apply optimizations, then press Enter to continue..."

echo
echo "=== AFTER Optimization ==="
wrk -t12 -c400 -d30s --latency $URL | tee after-wrk.txt

# Extract key metrics
echo
echo "=== Comparison ==="
echo "Before:"
grep "Requests/sec" before-wrk.txt
grep "50%" before-wrk.txt
echo "After:"
grep "Requests/sec" after-wrk.txt
grep "50%" after-wrk.txt

Results:

BEFORE Optimization:
Requests/sec:   2,340.12
50%   145.23ms

AFTER Optimization:
Requests/sec:   8,920.45 (281% improvement)
50%   38.67ms (73% faster)

siege Test:

#!/bin/bash
# compare-siege.sh

CONFIG="-c100 -t60s -i"
URLS="urls.txt"

echo "=== BEFORE Optimization ==="
siege $CONFIG -f $URLS 2>&1 | tee before-siege.txt

read -p "Apply optimizations, then press Enter..."

echo
echo "=== AFTER Optimization ==="
siege $CONFIG -f $URLS 2>&1 | tee after-siege.txt

echo
echo "=== Comparison ==="
echo "Before:"
grep "Transaction rate\|Response time\|Availability" before-siege.txt
echo "After:"
grep "Transaction rate\|Response time\|Availability" after-siege.txt

Scenario 2: Capacity Planning

#!/bin/bash
# capacity-test.sh

URL="http://localhost/"

echo "Testing capacity with increasing concurrency..."
echo "Concurrency,Requests/sec,Latency_p50,Latency_p99" > capacity-results.csv

for concurrency in 10 50 100 200 400 800 1600; do
    echo "Testing concurrency: $concurrency"

    result=$(wrk -t12 -c$concurrency -d30s --latency $URL 2>&1)
    rps=$(echo "$result" | grep "Requests/sec" | awk '{print $2}')
    p50=$(echo "$result" | grep "50%" | awk '{print $2}')
    p99=$(echo "$result" | grep "99%" | awk '{print $2}')

    echo "$concurrency,$rps,$p50,$p99" >> capacity-results.csv

    sleep 10  # Cool down between tests
done

echo "Results saved to capacity-results.csv"
cat capacity-results.csv

# Analyze results to find optimal concurrency

Sample Results:

Concurrency,Requests/sec,Latency_p50,Latency_p99
10,1250.23,8.45ms,24.12ms
50,4580.45,11.23ms,32.45ms
100,7840.12,13.67ms,45.23ms
200,9420.67,21.45ms,78.34ms
400,9680.34,41.23ms,156.78ms  <- Peak performance
800,8920.45,89.67ms,345.23ms  <- Degradation starts
1600,6450.23,245.78ms,890.45ms <- Severe degradation

Conclusion: Optimal concurrency around 400-500

Scenario 3: Sustained Load Testing

wrk Sustained Test:

# 10-minute sustained load test
wrk -t12 -c400 -d600s --latency http://localhost/

# Monitor during test (separate terminal):
watch -n 5 '
    echo "=== System Resources ==="
    mpstat 1 1 | tail -2
    echo
    free -h
    echo
    ss -s
'

# Look for:
# - Memory leaks (memory usage increasing)
# - Connection exhaustion (connections growing)
# - Performance degradation (response time increasing)

siege Sustained Test:

# 15-minute test with realistic delays
siege -c100 -t900s -i -d1 -f urls.txt

# -d1: 1 second random delay between requests (0-2 seconds)
# Simulates real user behavior

# Check log file for detailed transaction data
cat /var/log/siege.log

Scenario 4: API Stress Testing

wrk with POST Data:

-- api-stress.lua
local requests = 0
local errors = 0

request = function()
    requests = requests + 1

    local bodies = {
        '{"action":"create","data":{"name":"Item1"}}',
        '{"action":"update","data":{"id":1,"name":"Updated"}}',
        '{"action":"delete","data":{"id":2}}',
        '{"action":"list","page":1,"limit":10}'
    }

    local body = bodies[math.random(#bodies)]

    return wrk.format("POST", "/api/actions", {["Content-Type"] = "application/json"}, body)
end

response = function(status, headers, body)
    if status ~= 200 and status ~= 201 then
        errors = errors + 1
        print("Error: " .. status .. " after " .. requests .. " requests")
    end
end

done = function(summary, latency, requests)
    print("Total requests: " .. requests.requests)
    print("Total errors: " .. errors)
    print("Error rate: " .. string.format("%.2f%%", (errors / requests.requests) * 100))
end

wrk -t12 -c500 -d300s -s api-stress.lua http://localhost/

Scenario 5: Database Connection Pool Testing

-- db-pool-test.lua
-- Test database connection handling

local counter = 0
local slow_queries = 0

response = function(status, headers, body)
    local latency = tonumber(headers["X-Response-Time"] or "0")

    if latency > 1000 then  -- Queries > 1 second
        slow_queries = slow_queries + 1
    end
end

done = function(summary, latency, requests)
    print("\nDatabase Connection Pool Analysis:")
    print("Total queries: " .. summary.requests)
    print("Slow queries (>1s): " .. slow_queries)
    print("Slow query rate: " .. string.format("%.2f%%", (slow_queries / summary.requests) * 100))

    if slow_queries / summary.requests > 0.05 then
        print("\nWARNING: > 5% slow queries. Increase connection pool size.")
    end
end

Performance Comparison: ab vs wrk vs siege

#!/bin/bash
# tool-comparison.sh

URL="http://localhost/"
DURATION="30s"
CONCURRENCY=200

echo "=== Tool Comparison Test ==="
echo "URL: $URL"
echo "Duration: $DURATION"
echo "Concurrency: $CONCURRENCY"
echo

# Apache Bench
echo "1. Apache Bench:"
ab -n 10000 -c $CONCURRENCY -k $URL 2>&1 | grep -E "Requests per second|Time per request"
echo

# wrk
echo "2. wrk:"
wrk -t12 -c$CONCURRENCY -d$DURATION $URL 2>&1 | grep "Requests/sec"
echo

# siege
echo "3. siege:"
siege -c$CONCURRENCY -t$DURATION $URL 2>&1 | grep -E "Transaction rate|Response time"
echo

Typical Results (same server, same test):

1. Apache Bench:
Requests per second: 8,450.23
Time per request: 23.67ms

2. wrk:
Requests/sec: 9,120.45

3. siege:
Transaction rate: 8,890.12 trans/sec
Response time: 0.02 secs

Observations:
- wrk: Highest throughput (multi-threaded efficiency)
- ab: Good baseline, widely available
- siege: Best for complex scenarios and URL lists

Monitoring and Analysis

Real-Time Monitoring During Tests

#!/bin/bash
# monitor-during-test.sh

# Start monitoring in background
(
    while true; do
        echo "$(date '+%H:%M:%S') $(free -m | awk 'NR==2{print $3"MB"}') $(mpstat 1 1 | awk 'NR==4{print $3"%"}') $(ss -s | grep TCP: | awk '{print $2}')"
        sleep 5
    done
) > monitor.log &
MONITOR_PID=$!

# Run test
echo "Starting test..."
wrk -t12 -c400 -d120s --latency http://localhost/ > test-results.txt

# Stop monitoring
kill $MONITOR_PID

# Analyze monitor log
echo
echo "=== Resource Usage During Test ==="
awk '{sum1+=$2; sum2+=$3; sum3+=$4; count++} END {print "Avg Memory:", sum1/count, "Avg CPU:", sum2/count"%", "Avg Connections:", sum3/count}' monitor.log

Analyzing Results

#!/bin/bash
# analyze-results.sh

RESULTS="$1"

# Extract key metrics
RPS=$(grep "Requests/sec" $RESULTS | awk '{print $2}')
LATENCY_AVG=$(grep "Latency" $RESULTS | awk '{print $2}')
LATENCY_P50=$(grep "50%" $RESULTS | awk '{print $2}')
LATENCY_P99=$(grep "99%" $RESULTS | awk '{print $2}')

# Generate report
cat << EOF
=== Performance Analysis ===

Throughput: $RPS requests/sec

Latency Analysis:
- Average: $LATENCY_AVG
- 50th percentile (median): $LATENCY_P50
- 99th percentile: $LATENCY_P99

Performance Rating:
EOF

# Rate performance
if (( $(echo "$RPS > 10000" | bc -l) )); then
    echo "- Excellent throughput (>10k req/s)"
elif (( $(echo "$RPS > 5000" | bc -l) )); then
    echo "- Good throughput (5k-10k req/s)"
elif (( $(echo "$RPS > 1000" | bc -l) )); then
    echo "- Moderate throughput (1k-5k req/s)"
else
    echo "- Low throughput (<1k req/s) - needs optimization"
fi

Best Practices

1. Realistic Test Configuration

# Bad: Unrealistic concurrency
wrk -t1 -c10000 -d30s http://localhost/
# One thread can't handle 10,000 connections efficiently

# Good: Threads = CPU cores, reasonable concurrency
wrk -t12 -c400 -d30s http://localhost/

2. Warm-Up Period

# Warm up caches and JIT
echo "Warming up..."
wrk -t4 -c100 -d10s http://localhost/ > /dev/null

echo "Running actual test..."
wrk -t12 -c400 -d60s --latency http://localhost/

3. Progressive Load Testing

#!/bin/bash
# progressive-load.sh

for concurrency in 50 100 200 400 800; do
    echo "Testing with $concurrency concurrent connections..."
    wrk -t12 -c$concurrency -d30s http://localhost/ | grep "Requests/sec"

    # Cool down
    sleep 30
done

4. Multiple Test Runs

# Run 5 times and average
for i in {1..5}; do
    echo "Run $i:"
    wrk -t12 -c400 -d30s http://localhost/ | grep "Requests/sec"
done

5. Document Test Environment

# Document system specs
cat << EOF > test-environment.txt
Test Date: $(date)
Server: $(uname -n)
CPU: $(lscpu | grep "Model name" | cut -d: -f2)
RAM: $(free -h | grep Mem | awk '{print $2}')
Disk: $(df -h / | tail -1 | awk '{print $2}')
Network: $(ethtool eth0 2>/dev/null | grep Speed | cut -d: -f2)
OS: $(cat /etc/os-release | grep PRETTY_NAME | cut -d= -f2)

Web Server: $(nginx -v 2>&1 || apache2 -v 2>&1 | head -1)
PHP Version: $(php -v | head -1)
EOF

Conclusion

wrk and siege are powerful load testing tools offering advanced features beyond Apache Bench:

wrk Advantages:

Multi-threaded performance
Lua scripting for complex scenarios
Detailed latency distribution
High throughput capability
Low resource usage

siege Advantages:

Multiple URL support
Transaction-based testing
Realistic user simulation
Simple URL list files
Internet mode (random URLs)

Use Cases:

wrk: Maximum performance testing, API load tests, scripted scenarios
siege: Realistic user behavior, multiple endpoint testing, availability testing
Both: Comprehensive testing strategy

Key Metrics to Track:

Throughput (requests/sec)
Latency (p50, p95, p99)
Availability (success rate)
Resource usage (CPU, memory)
Error rate

By combining wrk's raw performance testing with siege's realistic scenario simulation, you can comprehensively evaluate and optimize your web server performance for production workloads.

Benchmarking with wrk and siege

Benchmarking with wrk and siege

Introduction

wrk: Modern HTTP Benchmarking

Installation

Basic Usage

Understanding wrk Output

Advanced Options

wrk Lua Scripting

Basic Script Structure

Advanced Script: Multiple Endpoints

Authentication Script

POST with Dynamic Data

siege: Transaction-Based Benchmarking

Installation

Basic Usage

Understanding siege Output

Multiple URLs (URL List)

POST Requests

Headers and Authentication

Configuration Options

Real-World Testing Scenarios

Scenario 1: Before/After Optimization Comparison

Scenario 2: Capacity Planning

Scenario 3: Sustained Load Testing

Scenario 4: API Stress Testing

Scenario 5: Database Connection Pool Testing

Performance Comparison: ab vs wrk vs siege

Monitoring and Analysis

Real-Time Monitoring During Tests

Analyzing Results

Best Practices

1. Realistic Test Configuration

2. Warm-Up Period

3. Progressive Load Testing

4. Multiple Test Runs

5. Document Test Environment

Conclusion

Latest Video

Get $20 Free Credit
