Static IP Configuration on Linux: Complete Guide for Netplan, NetworkManager, and ifupdown

Introduction

Configuring a static IP address on Linux servers is a fundamental skill for system administrators and DevOps engineers. Unlike dynamic IP addresses assigned by DHCP servers, static IP addresses remain constant, making them essential for servers, network infrastructure, and services that require predictable network addressing. Whether you're setting up a web server, database cluster, or network appliance, understanding how to configure static IP addresses across different Linux distributions is crucial for maintaining reliable and secure network connectivity.

This comprehensive guide covers static IP configuration across three major network management systems used in modern Linux distributions: Netplan (Ubuntu 18.04+), NetworkManager (RHEL, CentOS, Fedora), and the traditional ifupdown system (Debian). By mastering these configuration methods, you'll be equipped to handle network configuration on virtually any Linux distribution.

Why Use Static IP Addresses?

Static IP addresses offer several advantages for server environments:

  • Predictability: Services always bind to the same IP address, simplifying DNS configuration and firewall rules
  • Remote Access: Consistent IP addresses make SSH access and remote administration reliable
  • Network Services: Essential for servers hosting DNS, email, web services, and databases
  • Service Dependencies: Applications expecting specific IP addresses function correctly
  • Monitoring and Logging: Simplified tracking and correlation of network activity
  • Reduced DHCP Dependencies: Eliminates reliance on DHCP server availability

Prerequisites

Before configuring static IP addresses on your Linux system, ensure you have:

  • Root or sudo access to the target Linux server
  • Basic understanding of networking concepts (IP addresses, subnet masks, gateways)
  • SSH access to the server (if configuring remotely)
  • Backup of current network configuration files
  • Valid IP address, subnet mask, gateway, and DNS server information
  • Knowledge of your network interface name (eth0, ens33, enp0s3, etc.)

Checking Your Current Network Configuration

Before making changes, document your current network settings:

# View all network interfaces
ip addr show

# Display current routing table
ip route show

# Check DNS configuration
cat /etc/resolv.conf

# View current network connections
ss -tuln

Static IP Configuration with Netplan (Ubuntu 18.04+ and Derivatives)

Netplan is the default network configuration tool for Ubuntu 18.04 and later versions. It uses YAML configuration files to define network settings, which are then applied through underlying renderers like systemd-networkd or NetworkManager.

Understanding Netplan Architecture

Netplan acts as a network configuration abstraction layer, translating YAML files into configuration for backend renderers. This approach provides a consistent configuration experience across different Ubuntu versions and derivatives.

Step-by-Step Netplan Configuration

Step 1: Identify Network Interface

First, identify your network interface name:

ip link show

Common interface names include:

  • ens33, ens18 - VMware and VirtualBox
  • enp0s3, enp0s8 - Physical servers
  • eth0, eth1 - Older naming convention

Step 2: Backup Existing Configuration

Always create a backup before modifying network configuration:

sudo cp /etc/netplan/00-installer-config.yaml /etc/netplan/00-installer-config.yaml.backup

Step 3: Edit Netplan Configuration

Netplan configuration files are located in /etc/netplan/. Edit the main configuration file:

sudo nano /etc/netplan/00-installer-config.yaml

Replace the contents with your static IP configuration:

network:
  version: 2
  renderer: networkd
  ethernets:
    ens33:
      dhcp4: no
      addresses:
        - 192.168.1.100/24
      routes:
        - to: default
          via: 192.168.1.1
      nameservers:
        addresses:
          - 8.8.8.8
          - 8.8.4.4

Configuration breakdown:

  • network.version: 2 - Specifies Netplan version 2 syntax
  • renderer: networkd - Uses systemd-networkd as the backend (alternative: NetworkManager)
  • dhcp4: no - Disables DHCP for IPv4
  • addresses - Static IP address with CIDR notation (/24 = 255.255.255.0)
  • routes - Default gateway configuration
  • nameservers - DNS server addresses

Step 4: Validate Configuration Syntax

Before applying changes, validate the YAML syntax:

sudo netplan --debug generate

If no errors appear, the syntax is correct.

Step 5: Apply Configuration

Apply the new network configuration:

sudo netplan apply

For testing purposes, you can try the configuration with automatic rollback:

sudo netplan try

This command waits for confirmation before permanently applying changes, reverting automatically after 120 seconds if not confirmed.

Advanced Netplan Configurations

Multiple IP Addresses

Configure multiple IP addresses on a single interface:

network:
  version: 2
  renderer: networkd
  ethernets:
    ens33:
      dhcp4: no
      addresses:
        - 192.168.1.100/24
        - 192.168.1.101/24
        - 192.168.1.102/24
      routes:
        - to: default
          via: 192.168.1.1
      nameservers:
        addresses: [8.8.8.8, 8.8.4.4]

Static Routes

Add custom static routes:

network:
  version: 2
  renderer: networkd
  ethernets:
    ens33:
      dhcp4: no
      addresses:
        - 192.168.1.100/24
      routes:
        - to: default
          via: 192.168.1.1
        - to: 10.10.0.0/16
          via: 192.168.1.254
      nameservers:
        addresses: [8.8.8.8, 1.1.1.1]

Bond Interface Configuration

Configure network bonding for redundancy:

network:
  version: 2
  renderer: networkd
  ethernets:
    ens33:
      dhcp4: no
    ens34:
      dhcp4: no
  bonds:
    bond0:
      dhcp4: no
      interfaces:
        - ens33
        - ens34
      addresses:
        - 192.168.1.100/24
      routes:
        - to: default
          via: 192.168.1.1
      parameters:
        mode: active-backup
        primary: ens33
      nameservers:
        addresses: [8.8.8.8, 8.8.4.4]

Static IP Configuration with NetworkManager (RHEL, CentOS, Rocky Linux, Fedora)

NetworkManager is the default network configuration system for Red Hat-based distributions. It provides both command-line (nmcli) and text-based UI (nmtui) tools for network configuration.

Using nmcli (Command-Line Interface)

The nmcli tool offers powerful command-line network configuration capabilities.

Step 1: List Network Connections

View existing network connections:

nmcli connection show

Identify your connection name (e.g., "System eth0" or "Wired connection 1").

Step 2: Configure Static IP with nmcli

Configure static IP addressing:

# Set static IPv4 address
sudo nmcli connection modify "System eth0" ipv4.addresses 192.168.1.100/24

# Set gateway
sudo nmcli connection modify "System eth0" ipv4.gateway 192.168.1.1

# Set DNS servers
sudo nmcli connection modify "System eth0" ipv4.dns "8.8.8.8 8.8.4.4"

# Change from auto (DHCP) to manual
sudo nmcli connection modify "System eth0" ipv4.method manual

# Bring the connection down and up to apply changes
sudo nmcli connection down "System eth0"
sudo nmcli connection up "System eth0"

Step 3: Verify Configuration

Confirm the configuration:

nmcli connection show "System eth0"
ip addr show

Using nmtui (Text User Interface)

For those who prefer a text-based graphical interface:

sudo nmtui

Navigate through the interface:

  1. Select "Edit a connection"
  2. Choose your network interface
  3. Select "IPv4 CONFIGURATION" and change to "Manual"
  4. Add your IP address, gateway, and DNS servers
  5. Select "OK" and then "Activate a connection" to apply

Using Configuration Files Directly

NetworkManager stores connection profiles in /etc/NetworkManager/system-connections/ (RHEL 8+) or uses ifcfg files in /etc/sysconfig/network-scripts/ (RHEL 7).

For RHEL 7 and CentOS 7 (ifcfg files):

Edit the interface configuration file:

sudo nano /etc/sysconfig/network-scripts/ifcfg-eth0

Configure static IP:

TYPE=Ethernet
PROXY_METHOD=none
BROWSER_ONLY=no
BOOTPROTO=none
DEFROUTE=yes
IPV4_FAILURE_FATAL=no
NAME=eth0
DEVICE=eth0
ONBOOT=yes
IPADDR=192.168.1.100
PREFIX=24
GATEWAY=192.168.1.1
DNS1=8.8.8.8
DNS2=8.8.4.4

Restart networking:

sudo systemctl restart network
# Or for newer systems:
sudo nmcli connection reload
sudo nmcli connection up eth0

Static IP Configuration with ifupdown (Debian Traditional Method)

The traditional Debian networking system uses /etc/network/interfaces for configuration. While Debian 10+ often uses NetworkManager by default, many server installations still use ifupdown.

Step 1: Edit Interfaces Configuration

Edit the main network configuration file:

sudo nano /etc/network/interfaces

Step 2: Configure Static IP

Replace DHCP configuration with static settings:

# The loopback network interface
auto lo
iface lo inet loopback

# The primary network interface
auto eth0
iface eth0 inet static
    address 192.168.1.100
    netmask 255.255.255.0
    gateway 192.168.1.1
    dns-nameservers 8.8.8.8 8.8.4.4
    dns-search example.com

Alternative CIDR notation (Debian 10+):

auto eth0
iface eth0 inet static
    address 192.168.1.100/24
    gateway 192.168.1.1
    dns-nameservers 8.8.8.8 8.8.4.4

Step 3: Configure DNS Resolution

Edit DNS configuration:

sudo nano /etc/resolv.conf

Add DNS servers:

nameserver 8.8.8.8
nameserver 8.8.4.4
search example.com

To prevent DHCP from overwriting /etc/resolv.conf:

sudo chattr +i /etc/resolv.conf

Step 4: Restart Networking

Apply the configuration:

sudo systemctl restart networking
# Or
sudo ifdown eth0 && sudo ifup eth0

Advanced ifupdown Configurations

Multiple IP Addresses (IP Aliasing)

Configure additional IP addresses:

auto eth0
iface eth0 inet static
    address 192.168.1.100
    netmask 255.255.255.0
    gateway 192.168.1.1

auto eth0:0
iface eth0:0 inet static
    address 192.168.1.101
    netmask 255.255.255.0

auto eth0:1
iface eth0:1 inet static
    address 192.168.1.102
    netmask 255.255.255.0

Static Routes

Add custom routing:

auto eth0
iface eth0 inet static
    address 192.168.1.100
    netmask 255.255.255.0
    gateway 192.168.1.1
    dns-nameservers 8.8.8.8 8.8.4.4
    # Static route to 10.0.0.0/8 network
    up ip route add 10.0.0.0/8 via 192.168.1.254
    down ip route del 10.0.0.0/8 via 192.168.1.254

Verification and Testing

After configuring static IP addresses, thoroughly test your network configuration.

Basic Connectivity Tests

Verify IP Address Assignment

ip addr show
# Or older command
ifconfig

Look for your configured IP address on the correct interface.

Check Routing Table

ip route show
# Verify default gateway
ip route | grep default

Test Gateway Connectivity

ping -c 4 192.168.1.1

Test DNS Resolution

# Check DNS servers
cat /etc/resolv.conf

# Test DNS resolution
nslookup google.com
dig google.com

# Test with specific DNS server
nslookup google.com 8.8.8.8

Test Internet Connectivity

ping -c 4 8.8.8.8
ping -c 4 google.com

Advanced Network Testing

Check Network Interface Status

ip link show eth0
# Look for "state UP"

Test Network Performance

# Download speed test
wget -O /dev/null http://speedtest.tele2.net/100MB.zip

# MTU path discovery
ping -M do -s 1472 192.168.1.1

Verify Service Binding

# Check which services are listening
ss -tuln
netstat -tuln

# Check specific port
ss -tuln | grep :80

Troubleshooting Common Issues

Issue 1: Network Interface Not Coming Up

Symptoms: Interface shows "DOWN" state

Solutions:

# Check interface status
ip link show

# Bring interface up manually
sudo ip link set eth0 up

# For Netplan
sudo netplan apply

# For NetworkManager
sudo nmcli connection up "System eth0"

# For ifupdown
sudo ifup eth0

Issue 2: No Route to Gateway

Symptoms: Cannot ping gateway

Diagnosis:

ip route show

Solutions:

# Add default gateway manually
sudo ip route add default via 192.168.1.1

# Make permanent by updating configuration files

Issue 3: DNS Resolution Failure

Symptoms: Can ping IP addresses but not domain names

Diagnosis:

cat /etc/resolv.conf
nslookup google.com

Solutions:

# Update DNS servers in /etc/resolv.conf
sudo nano /etc/resolv.conf

# Add nameservers
nameserver 8.8.8.8
nameserver 1.1.1.1

# For systemd-resolved systems
sudo systemctl restart systemd-resolved

Issue 4: Configuration Not Persisting After Reboot

Symptoms: Static IP works until reboot

Solutions:

For Netplan:

# Verify configuration file
ls -la /etc/netplan/
sudo netplan apply

For NetworkManager:

# Ensure connection starts on boot
sudo nmcli connection modify "System eth0" connection.autoconnect yes

For ifupdown:

# Verify "auto" directive in /etc/network/interfaces
auto eth0

Issue 5: Conflicting IP Address

Symptoms: Network intermittently disconnects or shows duplicate IP warnings

Diagnosis:

# Check for IP conflicts
sudo arping -D -I eth0 192.168.1.100

Solutions:

  • Verify no other device uses the same IP address
  • Use a different IP address from the available pool
  • Configure DHCP server to exclude static IP range

Issue 6: Netplan YAML Syntax Errors

Symptoms: "netplan apply" fails with syntax errors

Solutions:

# Validate YAML syntax
sudo netplan --debug generate

# Common issues:
# - Incorrect indentation (use spaces, not tabs)
# - Missing colons after keys
# - Incorrect array syntax

Proper indentation example:

network:
  version: 2
  ethernets:
    ens33:
      addresses:
        - 192.168.1.100/24  # Note: 2 space indent for array items

Best Practices for Static IP Configuration

1. IP Address Planning and Documentation

  • Maintain an IP address management (IPAM) spreadsheet or database
  • Reserve IP ranges for static assignments (e.g., .100-.200)
  • Use DHCP for dynamic assignments outside static range
  • Document all static IP assignments with hostname, purpose, and assignment date

2. Network Configuration Backups

Always backup configuration before changes:

# Netplan backup
sudo cp /etc/netplan/*.yaml /root/netplan-backup/

# NetworkManager backup
sudo cp /etc/NetworkManager/system-connections/* /root/nm-backup/
sudo cp /etc/sysconfig/network-scripts/ifcfg-* /root/ifcfg-backup/

# ifupdown backup
sudo cp /etc/network/interfaces /etc/network/interfaces.backup

3. Use Configuration Management

For managing multiple servers, use configuration management tools:

  • Ansible playbooks for network configuration
  • Puppet or Chef recipes
  • Salt states
  • Version control for configuration files (Git)

4. DNS Best Practices

  • Configure at least two DNS servers for redundancy
  • Use reliable DNS providers (Google: 8.8.8.8, Cloudflare: 1.1.1.1)
  • Consider internal DNS servers for corporate environments
  • Set appropriate DNS search domains

5. Security Considerations

# Disable unused network interfaces
sudo ip link set eth1 down

# Configure firewall rules for static IP
sudo ufw allow from 192.168.1.0/24 to any port 22

# Restrict SSH to specific IPs in /etc/ssh/sshd_config
ListenAddress 192.168.1.100

6. Testing Procedures

Establish a testing checklist:

  1. Verify IP address assignment
  2. Test gateway connectivity
  3. Confirm DNS resolution
  4. Check Internet connectivity
  5. Verify service accessibility
  6. Test after server reboot
  7. Monitor for IP conflicts

7. Remote Configuration Safety

When configuring remotely via SSH:

# Use screen or tmux to prevent disconnection
screen

# For Netplan, use "netplan try" for automatic rollback
sudo netplan try

# Set up console/IPMI access before making changes
# Keep current SSH session open until verification

8. Monitoring and Alerts

Set up monitoring for network interface status:

# Create monitoring script
cat << 'EOF' | sudo tee /usr/local/bin/check_network.sh
#!/bin/bash
INTERFACE="eth0"
if ! ip link show $INTERFACE | grep -q "state UP"; then
    echo "Network interface $INTERFACE is down!" | mail -s "Network Alert" [email protected]
fi
EOF

sudo chmod +x /usr/local/bin/check_network.sh

# Add to crontab
echo "*/5 * * * * /usr/local/bin/check_network.sh" | sudo crontab -

Performance Optimization

MTU Configuration

Optimize Maximum Transmission Unit for your network:

Netplan:

network:
  version: 2
  ethernets:
    ens33:
      mtu: 9000
      addresses: [192.168.1.100/24]

NetworkManager:

sudo nmcli connection modify "System eth0" 802-3-ethernet.mtu 9000

ifupdown:

iface eth0 inet static
    mtu 9000

Network Interface Queue Length

Increase transmit queue length for high-traffic servers:

sudo ip link set eth0 txqueuelen 10000

Make permanent by adding to network configuration or rc.local.

Security Considerations

1. Firewall Configuration

After setting static IP, configure firewall rules:

# UFW (Ubuntu)
sudo ufw allow from 192.168.1.0/24 to 192.168.1.100 port 22
sudo ufw enable

# firewalld (RHEL/CentOS)
sudo firewall-cmd --permanent --add-rich-rule='rule family="ipv4" source address="192.168.1.0/24" port port="22" protocol="tcp" accept'
sudo firewall-cmd --reload

2. Network Segmentation

Place servers in appropriate network segments:

  • DMZ for public-facing servers
  • Internal network for databases and application servers
  • Management network for administrative access

3. Disable IPv6 if Not Used

If IPv6 is not required:

Netplan:

network:
  version: 2
  ethernets:
    ens33:
      dhcp6: no
      accept-ra: no

Sysctl:

sudo nano /etc/sysctl.conf
# Add:
net.ipv6.conf.all.disable_ipv6 = 1
net.ipv6.conf.default.disable_ipv6 = 1

sudo sysctl -p

4. MAC Address Filtering

For sensitive environments, consider MAC address filtering at the switch level and documentation:

# View MAC address
ip link show eth0 | grep link/ether

Conclusion

Configuring static IP addresses on Linux is a fundamental networking skill that every system administrator must master. Whether you're working with modern Ubuntu systems using Netplan, Red Hat-based distributions with NetworkManager, or traditional Debian systems with ifupdown, understanding the nuances of each approach ensures reliable network configuration across diverse environments.

Key takeaways from this guide:

  • Netplan provides a modern, YAML-based configuration approach for Ubuntu and derivatives
  • NetworkManager offers powerful CLI and TUI tools for Red Hat-based systems
  • ifupdown remains relevant for traditional Debian server deployments
  • Always backup configurations before making changes
  • Thoroughly test after configuration changes, especially before rebooting
  • Implement monitoring and documentation practices
  • Consider security implications of static IP assignments

By following the best practices outlined in this guide, you'll maintain stable, secure, and well-documented network configurations that form the foundation of reliable server infrastructure. Remember to adapt these configurations to your specific network environment and always test changes in a non-production environment when possible.

For ongoing learning, explore advanced topics such as network bonding, VLANs, and software-defined networking to further enhance your Linux networking expertise.
