HAProxy actively probes every backend server and removes it from rotation as soon as it stops answering correctly, then brings it back when it recovers. In this tutorial you will configure HTTP health checks against a dedicated /health endpoint on Ubuntu 24.04, tune how fast failures are detected, add a backup server, and watch failover happen through the logs, the stats page and the runtime API.

Prerequisites

To follow this tutorial you need:

  • A server running Ubuntu 24.04 LTS (for example a CubePath VPS). Debian 12 works the same way.
  • A non-root user with sudo privileges.
  • Python 3, which is preinstalled on Ubuntu, to run small test backends.

Ubuntu 24.04 ships HAProxy 2.8 LTS, which supports every directive used here.

Step 1 - Installing HAProxy and socat

Install HAProxy and socat, which you will use to talk to the HAProxy runtime API:

sudo apt update
sudo apt install haproxy socat

Check the version and that the service is running:

haproxy -v | head -n 1
systemctl is-active haproxy

HAProxy version 2.8.5-1ubuntu3 2024/04/01 - https://haproxy.org/
active

Step 2 - Starting three test backends

Create a web root for each backend. Each contains an index.html with its name and a health file that the health check will request:

for n in 1 2 3; do
  sudo mkdir -p "/srv/web$n"
  echo "web$n" | sudo tee "/srv/web$n/index.html" > /dev/null
  echo "OK" | sudo tee "/srv/web$n/health" > /dev/null
done

Start them as transient systemd services with Python's built-in web server. web1 and web2 are the primary servers, web3 will be the backup:

sudo systemd-run --unit=web1 python3 -m http.server 8081 --bind 127.0.0.1 --directory /srv/web1
sudo systemd-run --unit=web2 python3 -m http.server 8082 --bind 127.0.0.1 --directory /srv/web2
sudo systemd-run --unit=web3 python3 -m http.server 8083 --bind 127.0.0.1 --directory /srv/web3

Verify that each one answers on /health:

curl -s http://127.0.0.1:8081/health http://127.0.0.1:8082/health http://127.0.0.1:8083/health

OK
OK
OK

In production, /health should be an endpoint in your application that checks what the app really needs (database connection, disk, queue) and returns 200 only when it can serve traffic.

Step 3 - Configuring HTTP health checks

Open the HAProxy configuration:

sudo nano /etc/haproxy/haproxy.cfg

Keep the existing global and defaults sections. The Ubuntu package already defines mode http, logging to /dev/log and the runtime API socket at /run/haproxy/admin.sock. Append the following at the end of the file:

frontend web_front
    bind :80
    default_backend web_back

backend web_back
    balance roundrobin
    option httpchk
    http-check send meth GET uri /health ver HTTP/1.1 hdr Host localhost
    http-check expect status 200
    default-server inter 3s fall 3 rise 2
    server web1 127.0.0.1:8081 check
    server web2 127.0.0.1:8082 check
    server web3 127.0.0.1:8083 check backup

listen stats
    bind 127.0.0.1:8404
    stats enable
    stats uri /
    stats refresh 5s

What each health check line does:

  • option httpchk switches the checks from a plain TCP connect to an HTTP request.
  • http-check send defines the request: method, path, HTTP version and a Host header, which many applications require.
  • http-check expect status 200 marks the server as failed on any other status code. You can also match a range with expect rstatus ^2 or the body with expect string OK.
  • default-server inter 3s fall 3 rise 2 applies to every server line: check every 3 seconds, mark a server DOWN after 3 consecutive failures and UP again after 2 consecutive successes.
  • check on each server line enables checking for that server. Without it, HAProxy never checks the server and always considers it UP.
  • backup keeps web3 out of rotation until no primary server is UP.

With these values, a dead server is detected in about 9 seconds (3 checks x 3 seconds). Lower inter detects failures faster at the cost of more check traffic. fastinter and downinter let you check more often while a server is changing state or while it is down.

Validate the file and reload HAProxy:

sudo haproxy -c -f /etc/haproxy/haproxy.cfg
sudo systemctl reload haproxy

Configuration file is valid

Send a few requests. Only the primary servers answer:

for i in $(seq 4); do curl -s http://localhost/; done

web1
web2
web1
web2

Step 4 - Checking server status

Query the status column of each server through the runtime API. Field 1 is the backend, field 2 the server and field 18 the status:

echo "show stat" | sudo socat stdio /run/haproxy/admin.sock | cut -d, -f1,2,18 | grep web_back

web_back,web1,UP
web_back,web2,UP
web_back,web3,UP
web_back,BACKEND,UP

For a visual view, open the stats page. It only listens on localhost, so reach it through an SSH tunnel from your computer:

ssh -L 8404:127.0.0.1:8404 your_user@your_server_ip

Then browse to http://localhost:8404/. Each server shows its state, the result of the last check (for example L7OK/200) and how long it has been in that state.

Step 5 - Testing failover

Simulate an application failure on web1 by removing its health file. The process is still running, but /health now returns 404:

sudo rm /srv/web1/health

Follow the HAProxy log. After about 9 seconds HAProxy marks the server DOWN:

sudo tail -f /var/log/haproxy.log

2026-09-25T10:14:02.118+00:00 your_hostname haproxy[1520]: Server web_back/web1 is DOWN, reason: Layer7 wrong status, code: 404, info: "File not found", check duration: 1ms. 1 active and 1 backup servers left. 0 sessions active, 0 requeued, 0 remaining in queue.

Press Ctrl+C and confirm that all traffic now goes to web2:

for i in $(seq 4); do curl -s http://localhost/; done

web2
web2
web2
web2

Now stop web2 completely. HAProxy's check gets Connection refused and marks it DOWN with a Layer4 error:

sudo systemctl stop web2

After a few seconds the backup server takes over:

for i in $(seq 2); do curl -s http://localhost/; done

web3
web3

Restore both servers:

echo "OK" | sudo tee /srv/web1/health > /dev/null
sudo systemd-run --unit=web2 python3 -m http.server 8082 --bind 127.0.0.1 --directory /srv/web2

After two successful checks (about 6 seconds with rise 2), both are back and web3 returns to standby:

echo "show stat" | sudo socat stdio /run/haproxy/admin.sock | cut -d, -f1,2,18 | grep web_back

web_back,web1,UP
web_back,web2,UP
web_back,web3,UP
web_back,BACKEND,UP

Step 6 - Tuning failover behavior

A few extra options make failover smoother. Add them to the web_back backend:

    option redispatch
    retries 2
    default-server inter 3s fall 3 rise 2 on-marked-down shutdown-sessions slowstart 30s
  • option redispatch lets HAProxy send a request to another server if the connection to the chosen one fails, even when a persistence cookie points to the dead server.
  • retries 2 sets how many connection attempts HAProxy makes before giving up.
  • on-marked-down shutdown-sessions closes open connections to a server as soon as it is marked DOWN, so long-lived clients reconnect to a healthy server instead of hanging.
  • slowstart 30s ramps traffic to a recovered server up over 30 seconds instead of sending it a full share at once, which protects applications with cold caches.

If you have several backup servers and want all of them to share the load when the primaries fail, add option allbackups. Without it, only the first backup receives traffic.

Validate and reload after the change:

sudo haproxy -c -f /etc/haproxy/haproxy.cfg && sudo systemctl reload haproxy

Step 7 - Health checking TCP services

For non-HTTP services, run the backend in mode tcp. A plain check then verifies that a TCP connection can be established. Some protocols have dedicated checks, such as option redis-check, which sends a PING and expects +PONG:

listen redis
    bind 127.0.0.1:6380
    mode tcp
    option redis-check
    server redis1 10.0.0.21:6379 check inter 2s fall 3 rise 2
    server redis2 10.0.0.22:6379 check inter 2s fall 3 rise 2 backup

Replace the addresses with your own Redis servers. A TCP connect check only proves that the port is open. When possible, prefer a protocol-level check or an HTTP health endpoint exposed by the service.

Step 8 - Draining a server for maintenance

Health checks handle unplanned failures. For planned work, drain the server through the runtime API: it stops receiving new connections but finishes the current ones.

echo "set server web_back/web1 state drain" | sudo socat stdio /run/haproxy/admin.sock

When the maintenance is over, put it back into rotation:

echo "set server web_back/web1 state ready" | sudo socat stdio /run/haproxy/admin.sock

Use state maint instead of drain to stop traffic and checks immediately. These changes are not saved to the configuration and are lost on a restart.

Troubleshooting

  • Server is DOWN with Layer7 wrong status, code: 400: the application rejects the check request, usually because of a missing or wrong Host header. Adjust hdr Host in http-check send.
  • Server is DOWN with Layer4 connection problem: nothing listens on that address and port, or a firewall blocks HAProxy. Test from the HAProxy host with curl -v http://backend_ip:port/health.
  • Server is always UP even though it is broken: the server line is missing the check keyword, or the health endpoint returns 200 without testing anything.
  • /var/log/haproxy.log is empty: HAProxy logs through rsyslog on Ubuntu. Check systemctl status rsyslog and restart it with sudo systemctl restart rsyslog.

Conclusion

HAProxy now checks every backend over HTTP, removes failed servers in about 9 seconds, promotes a backup server when all primaries are down, and brings recovered servers back gradually. You also learned how to read server state from the runtime API and drain servers for maintenance.

As next steps, point the checks at a real application health endpoint, enable TLS on the frontend, and run two HAProxy nodes with keepalived and a floating IP so the load balancer itself is not a single point of failure.
